Efficient Hybrid Image Warping for High Frame-Rate Stereoscopic Rendering

Modern virtual reality simulations require a constant high-frame rate from the rendering engine. They may also require very low latency and stereo images. Previous rendering engines for virtual reality applications have exploited spatial and temporal coherence by using image-warping to re-use previous frames or to render a stereo pair at lower cost than running the full render pipeline twice. However these previous approaches have shown artifacts or have not scaled well with image size. We present a new image-warping algorithm that has several novel contributions: an adaptive grid generation algorithm for proxy geometry for image warping; a low-pass hole-filling algorithm to address un-occlusion; and support for transparent surfaces by efficiently ray casting  transparent fragments stored in  per-pixel linked lists of an A-Buffer. We evaluate our algorithm with a variety of challenging test cases. The results show that it achieves better quality image-warping than state-of-the-art techniques and that it can support transparent surfaces effectively. Finally, we show that our algorithm can achieve image warping at rates suitable for practical use in a variety of applications on modern virtual reality equipment.


Schollmeyer, A., Schneegans, S., Beck, S., Steed, A., Froehlich, B.
Efficient Hybrid Image Warping for High Frame-Rate Stereoscopic Rendering
In IEEE Transactions on Visualization and Computer Graphics 23(4), pp. 1332 - 1341, 2017, and In Proceedings of IEEE VR 2017, Los Angeles, USA, March 2017. DOI: https://doi.org/10.1109/TVCG.2017.2657078
