Construction progress monitoring

Video based Progress Monitoring of Finishing Works based on 4D Building Information Models

The execution of finishing works is usually characterized by deviations from the planned schedule. On the one hand, this is due to the inherent design uncertainties and, on the other hand, due to inevitable disruptions and design changes. For this reason, continuous progress monitoring is crucial to instantly take appropriate actions. Currently, progress monitoring is a very labor intensive, time consuming and subjective process, since on-site data is manually captured and aligned with project information. Accordingly, deviations from schedule are frequently recognized too late, leading to extensive and costly counteractions and design changes. Consequently, robust and efficient construction execution requires real-time, transparent and accurate progress monitoring.

In this research project, innovative and fundamental methods for automated progress monitoring of finishing works using video-based as-built data and 4D as-designed building information models (BIM) are developed. This includes, for example, methods for model-based position and orientation estimation of the camera in order to register videos within the 4D BIM. Consequently, building design information can directly be mapped onto the captured image data. On this basis, machine vision and learning methods are designed to detect and recognize relevant finishing items and their completion states. For this purpose, progress and viewing direction dependent object and state features are defined and stored in an extendable object catalogue. Additionally, novel concepts to store and link relevant position, geometry and material classifiers for finishing items based on the 4D BIM as well as their continuous adaption are the focus of this research. The results are expected to significantly improve the accuracy, the robustness, and the efficiency of progress monitoring for finishing works.

Automatic activity state recognition with BIM-registered videos

Click the Play button to load and view external content from

Automatically load and view external content from (You can change this setting at any time via our »Data protection policy«.)

Kropp, Christopher; Koch, Christian; Koenig, Markus (2018). Interior construction state recognition with 4D BIM registered image sequences. Automation in Construction 86 11-32.

Kropp, Christopher; Koch, Christian; Koenig, Markus (2015). Integrating visual state recognition with 4D BIM based indoor progress monitoring. In: Proc. of the 22nd EG-ICE International Workshop. Eindhoven. Netherlands.

Kropp, Christopher; Koch, Christian; Koenig, Markus (2014). Drywall state detection in image data for automatic indoor progress monitoring. In: Proc. of the 2014 International Conference on Computing in Civil and Building Engineering (ICCCBE 2014). Orlando. USA.

Kropp, Christopher; Koenig, Markus; Koch, Christian (2013). Object Recognition in BIM Registered Videos for Indoor Progress Monitoring. In Proceedings of the 2013 EG-ICE International Workshop on Intelligent Computing in Engineering. Vienna. Austria.

Kropp, Christopher; Koch, Christian; Brilakis, Ioannis; Koenig, Markus (2012). A framework for automated delay prediction of finishing works using video data and BIM-based construction simulation. In: Proceedings of the 14th International Conference on Computing in Civil and Building Engineering. Moskau/ Russia.
